8 Inch Commercial Android Smart Terminal OEM Touchscreen Camera Ethernet for Business Applications

The SN808T is an 8-inch Android interactive terminal designed for commercial digital solutions in restaurant, retail, hospitality, and enterprise environments.

Size:

8 Inch

Resolution:

1280×800

Viewing angle:

85/85/85/85(L/R/U/D)

Brightness:

300 cd/m2

Contrast:

1000

CPU:

Allwinner A133 quad core 64 bit Cortex-A53

RAM&Internal memory:

1GB+16GB



The SN808T is an 8-inch Android commercial terminal designed for businesses that need a compact interactive device for daily operations, customer engagement, and digital workflow integration. Unlike consumer tablets, commercial terminals need to consider installation space, system compatibility, network stability, and long-term deployment requirements.

With an L-shaped structure, touchscreen interface, Android operating system, integrated camera, speaker, microphone, and flexible connectivity options, the SN808T provides a practical hardware foundation for restaurants, retail stores, service counters, and enterprise applications.

Key Features

  • 8-inch Android commercial terminal with compact L-shaped design
  • Android 10 system powered by Allwinner A133 quad-core processor
  • 10-point capacitive touchscreen for efficient business interaction
  • 1280×800 display with 300 cd/m² brightness
  • Built-in 2.0MP camera, microphone, and dual speakers
  • Supports WiFi, Bluetooth 5.2, Ethernet, and USB connectivity
  • Optional cellular connectivity for flexible deployment scenarios
  • HDMI output and TF card expansion for system integration

Technical Specifications

Display Panel 8" high-definition full view screen
Resolution 1280×800
Viewing angle 85/85/85/85(L/R/U/D)
Brightness 300 cd/m2
Contrast 1000:1
Screen scale/Display area 16:10/ Display area : 173×109mm
System CPU Allwinner A133 quad core 64 bit Cortex-A53
RAM 1GB (2GB optional)
Internal memory 16GB(32GB optional)
Operation system Android 10 OS
Touch screen 10-Point capacitive touch
Network WIFI 802.11b/g/n
Ethernet 100M ethernet
Bluetooth BT 5.2
4G/5G  Cellular network Optional
Interface TF TF card slots
USB 2.0 2×USB 2.0 interface (support U disk, mouse, keyboard, printer etc)
RJ45 Ethernet interface (POE function Optional)
Earphone 1×3.5mm headphone Interface
HDMI 1xHDMI out
Power DC power input (5.5x2.1)
Multi-Media Video Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P)
Audio Support MP3, WMA, AAC and so on
Picture JPEG、JPG
Other parameters Microphone One microphones
Speaker 2×2W speakers
Camera Standard 2.0MP pixel camera (5.0MP pixel camera optional)
Working temp 0-50degree
OSD language Multi-language
Certificates 3C,FCC,CE,ROHS etc.
Attachment Adapter One, specifications: 12V/2A
User's Manual yes
Anti-theft Cap One
Detachable Stand One
Screws Three ,1 bracket screw, 2 cover screws



Product Highlights

Android Platform Supporting Flexible Application Deployment

The SN808T runs on Android 10 with an Allwinner A133 quad-core processor, providing a stable platform for commercial applications. Businesses can deploy customized software for ordering, information management, customer interaction, inventory checking, or internal workflows.

For system integrators, Android compatibility simplifies software adaptation and allows the terminal to work with existing application ecosystems. Whether used as a standalone device or part of a larger digital solution, the platform provides flexibility for different project requirements.

Touchscreen Interaction for Daily Commercial Use

The 8-inch display with 1280×800 resolution and 10-point capacitive touch technology is designed for close-range interaction scenarios. In commercial environments, operators often perform repeated actions throughout the day, making responsive touch performance an important part of workflow efficiency.

The compact screen size makes the device suitable for applications where users interact with information directly at a counter or workstation. With 300 cd/m² brightness and wide viewing angles, the display provides clear visibility in typical indoor business environments.

Flexible Connectivity for System Integration Projects

Commercial terminals rarely operate independently. They usually need to communicate with software platforms, network systems, and external devices.

The SN808T includes WiFi, Bluetooth 5.2, Ethernet, USB interfaces, TF card expansion, HDMI output, and optional cellular connectivity. These options allow integrators to select connection methods based on different installation conditions.

In retrofit projects, existing infrastructure can create practical challenges. Some locations may require wired network connections, while others need wireless deployment due to space limitations. The SN808T provides connectivity flexibility to adapt to different business environments.

Built-In Functions Supporting Interactive Applications

The SN808T integrates a 2.0MP camera, microphone, dual speakers, and multimedia support, allowing businesses to develop applications beyond basic touchscreen operation.

These integrated components can support scenarios involving communication, customer interaction, information display, or digital service processes. For example, retail solutions may combine product information with customer assistance, while enterprise applications may integrate audio and visual interaction into workflow systems.

By combining multiple functions in one device, the terminal helps reduce additional hardware requirements during deployment.

Designed for Retail, Enterprise and Digital Service Applications

Retail and enterprise environments increasingly require flexible digital touchpoints. A small interactive terminal can support customer assistance, employee access, registration processes, information lookup, or customized business applications.

The SN808T is designed as an adaptable Android hardware platform rather than a single-purpose device. This allows software companies, distributors, and system integrators to build different solutions around the same hardware foundation.

For businesses managing multiple locations, using a standardized terminal platform can simplify deployment, maintenance, and future expansion.

Built for Long-Term Deployment and Maintenance

Commercial hardware needs to fit into real operational environments where reliability and maintenance efficiency are important considerations. Devices may need to operate continuously, be replaced quickly, and remain compatible with existing software systems.

The SN808T supports standard accessories, flexible installation options, and commercial operating conditions suitable for indoor deployment. Its standardized hardware design helps businesses simplify device management during larger rollouts.

For companies deploying digital terminals across restaurants, retail locations, or enterprise facilities, consistent hardware planning can reduce operational complexity over time.

A Flexible Android Terminal Platform for Business Solutions

The SN808T 8-inch Android L-shaped smart terminal combines compact design, touchscreen interaction, Android compatibility, and integration flexibility for commercial applications.

From restaurant technology providers and retail solution companies to enterprise software developers and hardware distributors, the device provides a practical foundation for building customized digital workflows.

By focusing on deployment requirements rather than only hardware specifications, the SN808T helps businesses introduce interactive technology into real working environments with greater flexibility and scalability.



FAQ



What applications is this 8-inch Android Smart Terminal designed for

This terminal is designed for commercial interactive applications that require a compact Android-based device, including retail service terminals, restaurant ordering systems, smart building controls, healthcare information points, and enterprise workflow terminals. It is suitable for projects requiring touchscreen interaction, network connectivity, and flexible system integration.

Can this Android terminal be integrated with existing business software

Yes. The terminal runs on Android 10, allowing system integrators to install and deploy Android applications according to project requirements. It can be integrated with business systems such as ordering platforms, information management software, customer service applications, and customized enterprise solutions.

What connectivity options are available for different deployment environments

The terminal supports multiple communication methods, including WiFi, Ethernet, and Bluetooth for flexible installation and operation. Optional 4G/5G connectivity and POE support are available for projects requiring remote deployment, centralized management, or simplified wiring solutions.

What warranty and technical support options are available for B2B customers

The standard warranty period is 12 months, with extended warranty options available for long-term projects. Technical support includes remote troubleshooting, firmware assistance, integration guidance, and after-sales service support for distributors and system integration partners.

Can customers evaluate samples before placing a bulk order

Yes. Sample orders are available for customers who need to verify product performance, software compatibility, peripheral integration, and installation requirements before mass deployment. Sample testing helps reduce project risks and ensures the product meets application requirements.

What information should buyers provide before requesting a quotation

Buyers should provide key project details such as application scenario, estimated order quantity, required configuration, installation method, and customization requirements. This information helps suppliers recommend a suitable solution and provide a more accurate quotation and delivery plan.
